MIL-L-80061B
4.5.2 Alignment accuracy test. The machine shall be tested in accordance
with the builder's standard test methods to determine that it complies with
the alignment accuracy requirements of 3.7.
4.6 Packaging inspection. Packaging shall be inspected to determine com-
pliance with the requirements of Section 5.
5.
PACKAGING
5.1 Packaging - packing and markings. Unless otherwise specified, packaging,
packing and marking shall be in accordance with ASTM Standard D 3951. When
required, level A packaging and level A or B packing and marking shall be in
accordance with the applicable requirements of MIL-M-18058. The required levels
and special marking shall be as specified (see 6.2.1).
6. NOTES
6.1 Intended use. The lathes covered by this specification are intended
for use in production shops, toolrooms or laboratories to produce small parts
or to perform additional operations such as turning, drilling, and boring to
close tolerances at high speeds.
6.2 Ordering data.
6.2.1 Acquisition requirements.
Acquisition documents should specify the
following:
Title, number and date of this specification.
Type lathe required (see 1.2).
First article approval, if required (see 3.1).
c.
d.
If machine is required to be configured in a specific measurement
system (US or SI), state required system (see 3.2.1).
If measuring and indicating devices are required to be graduated in
e.
a specific measurement system (US or SI), state required system
(see 3.2.1.1).
f.
Dual calibrations (US and SI), if required (see 3.2.1.2).
Additional safety and health requirements (see 3.2.4 and 6.4).
g.
Painting, if different (see 3.3.5).
h.
Specify threaded type spindle nose, if required (see 3.4.4).
i.
Electrical system, if different (see 3.4.5).
j.
k.
Type motor enclosure, if different (see 3.4.6).
l
Special accuracy collets, if required (see talbe II) .
Standard equipment type I lathe, if different (see 3.8) .
m.
Specify chuck and chuck jaws required (see 3.8. 9)
n.
Standard equipment type II lathe, if different (see 3.9).
o.
Specify chuck and chuck jaws required (see 3.4.9).
p.
Optional equipment, as required (see 3.10).
q.
r.
Additional requirements, as required (see 3.11).
Lubrication chart or plate, if different (see 3.12).
s.
Nameplate, if different (see 3.13),
t.
14
