MIL-L-23249D
17 October 1984
SUPERSEDING
MIL-L-23249C
15 August 1973
MILITARY SPECIFICATION
LATHES, ENGINE AND TOOL ROOM 13 THRU 17 INCH
This specification is approved for use by all Departments and Agencies of
the Department of Defense.
1. SCOPE .
1.1 Scope. This specification covers electric motor driven, metal
turning and threading, engine and toolroom lathes. The lathes shall have
either geared head drive or combination gear and belt drive with equipment
and accessories as described herein.
1.2 Classification. This specification covers lathes of the following
types and sizes. The type and sizes furnished shall be as specified, (see
6.2.1).
Type I
- Engine lathes
Type II - Toolroom lathes
Swing over bed
Swing over cross slide
Inches
Inches
Size
(mm)
(mm)
(177)
(330)
7
1307
13
1508
15
(381)
8
(203)
(406)
1610
16
10
(254)
(228)
(431)
9
1709
17
Beneficial comments (recommendations, additions, deletions) and any
pertinent data which may be of use in improving this document should
be addressed to: Defense Industrial Plant Equipment Center, ATTN:
DIPEC-SSM, Memphis, Tennessee 38114-5297, by using the self-addressed
Standardization Document Improvement Proposal (DD Form 1426) appearing
at the end of this document or by letter.
FSC 3416
